Small Remote Display For Weighing Controller - RD3

Product Variant RD3

Quantity

$141.88 AUD

Sale Sold out

Description

A compact remote display that can be panel mounted or desk mounted and connects to the PT200M, PT200P, PT200X and PT600R indicators without needing any RD3 configuration.

RD3

	RD3 Datasheet
	Product Brochure and Specifications

SPECIFICATIONS

Display	20mm LCD, 6 digits, LED backlighting.
Update Rate	10 updates per second
Temperature	-10 ~ 50°C
Humidity	<90% non condensing
PT200M/P/X & PT600R Indicators	Auto-detects all A, B, & C outputs

Power Supply	12~24VDC or 4x AA alkaline cells with optional desk mount.
Communications	RS-232 - 2 wire (receive only)
Case Materials	ABS, Silicon Rubber, Nylon, Acrylic (no halogen used)
Dimensions	164x77x35 mm (as panel mount).
Options	Desk mount shell and battery compartment.
Weight	0.36kg

Click on the individual products below for more details, documentation and related products.

Prices exclude GST

	RD3 Compact Remote Display EPRD3IN0000XXX - RD3 Compact Remote Display	P.O.A

RD3 Compact Remote Display
EPRD3IN0000XXX - RD3 Compact Remote Display

P.O.A
